Introduction
Redis is an in-memory, key-value cache and store (a database, that is) that can also be persisted (saved permanently) to disk. In this article, you'll read how to back up a Redis database on an Ubuntu 14.04 server.
Redis data, by default, are saved to disk in a .rdb file, which is a point-in-time snapshot of your Redis dataset. The snapshot is made at specified intervals, and so is perfect for your backups.
Prerequisites
To complete the steps in this tutorial, you'll need:
An Ubuntu 14.04 server
Install Redis. You can follow just the master setup from this Redis setup tutorial (although it will work just as well with a master-slave cluster)
Make sure that your Redis server is running
If a Redis password was set, which is highly recommended, have it handy. The password is in the Redis configuration file - /etc/redis/redis.conf
Step 1 — Locating the Redis Data Directory
Redis stores its data in a directory on your server, which is what we want to back up. First we need to know where it is.
In Ubuntu and other Linux distributions, the Redis database directory is /var/lib/redis. But if you're managing a server that you inherited and the Redis data location was changed, you can locate it by typing:
sudo locate *rdb
Alternatively, you may also find it from the redis-cli prompt. To do that, type:
redis-cli
If the Redis server is not running, the response will be:
Output
Could not connect to Redis at 127.0.0.1:6379: Connection refused
not connected>
In that case, start Redis and reconnect using the following commands:
sudo service redis-server start
redis-cli
The shell prompt should now change to:
127.0.0.1:6379>
While connected to Redis, the next two commands will authenticate to it and get the data directory:
auth insert-redis-password-here
config get dir
The output of the last command should be your Redis data directory:
Output
1) "dir"
2) "/var/lib/redis"
Make note of your Redis directory. If it's different than the directory shown, make sure you use this directory throughout the tutorial.
You can exit the database command line interface now:
exit
Check that this is the correct directory:
ls /var/lib/redis
You should see a dump.rdb file. That's the Redis data. If appendonly is also enabled, you will also see an appendonly.aof or another .aof file, which contains a log of all write operations received by the server.
See this post about Redis persistence for a discussion of the differences between these two files. Basically, the .rdb file is a current snapshot, and the .aof file preserves your Redis history. Both are worth backing up.
We'll start with just the .rdb file, and end with an automated backup of both files.
(Optional) Step 2 — Adding Sample Data
In this section you can create some sample data to store in your Redis database. If you already have data on your server, you can just back up your existing content.
Log in to the database command line interface:
redis-cli
Authenticate:
auth insert-redis-password-here
Let's add some sample data. You should get a response of OK after each step.
SET shapes:triangles "3 sides"
SET shapes:squares "4 sides"
Confirm that the data was added.
GET shapes:triangles
GET shapes:squares
The output is included below:
Output
"3 sides"
"4 sides"
To commit these changes to the /var/lib/redis/dump.rdb file, save them:
save
You can exit:
exit
If you'd like, you can check the contents of the dump file now. It should have your data, albeit in a machine-friendly form:
sudo cat /var/lib/redis/dump.rdb
/var/lib/redis/dump.rdb
REDIS0006?shapes:squares4 sidesshapes:triangles3 sides??o????C
Step 3 — Backing Up the Redis Data
Now that you know where your Redis data are located, it's time to make the backup. From the official Redis website comes this quote:
Redis is very data backup friendly since you can copy RDB files while the database is running: the RDB is never modified once produced, and while it gets produced it uses a temporary name and is renamed into its final destination atomically using rename(2) only when the new snapshot is complete.
So, you can back up or copy the database file while the Redis server is running. Assuming that you're backing it up to a directory under your home folder, performing that backup is as simple as typing:
sudo cp /var/lib/redis/dump.rdb /home/sammy/redis-backup-001
Redis saves content here periodically, meaning that you aren't guaranteed an up-to-the-minute backup if the above command is all you run. You need to save your data first.
However, if a potentially small amount of data loss is acceptable, just backing up this one file will work.
Saving the Database State
To get a much more recent copy of the Redis data, a better route is to access redis-cli, the Redis command line.
Authenticate as explained in Step 1.
Then, issue the save command like so:
save
The output should be similar to this:
Output
OK
(1.08s)
Exit the database.
Now you may run the cp command given above, confident that your backup is fully up to date.
While the cp command will provide a one-time backup of the database, the best solution is to set up a cron job that will automate the process, and to use a tool that can perform incremental updates and, if needed, restore the data.
Step 4 — Configuring Automatic Updates with rdiff-backup and Cron
In this section, we'll configure an automatic backup that backs up your entire Redis data directory, including both data files.
There are several automated backup tools available. In this tutorial, we'll use a newer, user-friendly tool called rdiff-backup.
rdiff-backup a command line backup tool. It's likely that rdiff-backup is not installed on your server, so you'll first have to install it:
sudo apt-get install -y rdiff-backup
Now that it's installed, you can test it by backing up your Redis data to a folder in your home directory. In this example, we assume that your home directory is /home/sammy:
Note that the target directory will be created by the script if it does not exist. In other words, you don't have to create it yourself.
With the --preserve-numerical-ids, the ownerships of the source and destination folders will be the same.
sudo rdiff-backup --preserve-numerical-ids /var/lib/redis /home/sammy/redis
Like the cp command earlier, this is a one-time backup. What's changed is that we're backing up the entire /var/lib/redis directory now, and using rdiff-backup.
Now we'll automate the backup using cron, so that the backup takes place at a set time. To accomplish that, open the system crontab:
sudo crontab -e
(If you haven't used crontab before on this server, select your favorite text editor at the prompt.)
At the bottom of the filek append the entry shown below.
crontab
0 0 * * * rdiff-backup --preserve-numerical-ids --no-file-statistics /var/lib/redis /home/sammy/redis
This Cron entry will perform a Redis backup every day at midnight. The --no-file-statistics switch will disable writing to the file_statistics file in the rdiff-backup-data directory, which will make rdiff-backup run more quickly and use up a bit less disk space.
Alternately, you can use this entry to make a daily backup:
@daily rdiff-backup --preserve-numerical-ids --no-file-statistics /var/lib/redis /home/sammy/redis
For more about Cron in general, read this article about Cron.
As it stands, the backup will be made once a day, so you can come back tomorrow for the final test. Or, you can temporarily increase the backup frequency to make sure it's working.
Because the files are owned by the redis system user, you can verify that they are in place using this command. (Make sure you wait until the backup has actually triggered):
ls -l /home/sammy/redis
Your output should look similar to this:
Output
total 20
-rw-rw---- 1 redis redis 70 Sep 14 13:13 dump.rdb
drwx------ 3 root root 12288 Sep 14 13:49 rdiff-backup-data
-rw-r----- 1 redis redis 119 Sep 14 13:09 redis-staging-ao.aof
You'll now have daily backups of your Redis data, stored in your home directory on the same server.
Conclusion
Backing up your Redis data in the manner given in this article is good for when you don't mind backing up the data to a directory on the same server.
The most secure approach is, of course, to back up to a different machine. You can explore more backup options by reading this article about backups:
How To Choose an Effective Backup Strategy for your VPS
You can use many of these backup methods with the same files in the /var/lib/redis directory.
Keep an eye out for our future article about Redis migrations and restorations. You may also want to reference the rdiff-backup documentation's examples for how to use rdiff-backup effectively:
rdiff-backup Examples
